Adam Equipment – Analytical Balance (Luna)

Luna analytical balances are designed with an array of features and functions that accommodate most lab applications. The Luna range offers improved performance for faster, more accurate readings. With stylish, modern backlighting, Luna’s impressive display gives an aura of smart sophistication. The LCD features large, readily discernible 24mm digits in white on a black background. Multilingual text and display capability make Luna well-suited for users in various regions.

Performance and style for an impressive weighing experience

For simple operation, navigation buttons are color-coded, helping users perform functions with minimal training. Luna provides USB and RS-232 interfaces to facilitate data collection and transmission to computers or printers. ABS plastic construction and rugged grade 304 stainless steel pan mean Luna is easy to clean and can withstand demanding lab use. Available in four models with capacities up to 250g, Luna offers a readability of 0.0001g and can perform basic and detailed measuring tasks.

Adam Equipment – Analytical Balance (Luna)

Key Features

Hardware

  • Color-coded keys facilitate quick recognition of the most frequently used buttons
  • Level indicator and adjustable feet ensure proper balance setup for optimum weighing results
  • Security slot for optional Kensington-type lock and cable to help prevent theft
  • Large, grade 304 stainless steel pan allows swift cleaning
  • Sealed keypad protects against dirt and spills
  • USB and RS-232 interfaces provide speedy communication with computers and printers

Software

  • External calibration allows for verification and adjustment with weights
  • Hold function freezes the displayed weight, allowing time to elapse without losing the result
  • Multilingual display allows use in many different countries
  • Parts counting with preset sample sizes
  • Printouts include date and time for data tracking within Good Laboratory Practices (GLP) guidelines
  • Selectable digital filtering for animal/dynamic weighing enables consistent results for moving subjects
  • Auto power-off to save energy

Display

  • Vivid, backlit LCD easily visible in any lighting conditions

Specifications

Model LAB 84e LAB 124e LAB 214e LAB 254e LAB 84i LAB 124i LAB 214i LAB 254i
Capacity 80g 120g 210g 250g 80g 120g 210g 250g
Readability 0.0001g 0.0001g 0.0001g 0.0001g 0.0001g 0.0001g 0.0001g 0.0001g
Repeatability (S.D.) 0.0001g 0.0001g 0.0001g 0.0001g 0.0001g 0.0001g 0.0001g 0.0001g
Linearity (+/-) 0.0002g 0.0002g 0.0002g 0.0003g 0.0002g 0.0002g 0.0002g 0.0003g
Minimum Weight (USP, Typical) 0.002g 0.002g 0.002g 0.002g 0.002g 0.002g 0.002g 0.002g
Pan Size 80mm ø
Weighing Units mg, g, ct, GN, N, dr, oz, ozt, dwt, mm, tl.T, tl.H, tl.S, T, custom unit
Stabilisation Time (sec) 2
Interface RS-232 / USB
Calibration External calibration Internal automatic calibration / External calibration
Display Backlit LCD with 24mm high digits
Power Supply 18VDC 50/60Hz 830mA adapter
Operating Temperature 15° to 35°C
Housing ABS plastic
Draught Shield Chamber 192 x 195 x 230 mm
Overall Dim. 224 x 374 x 338 mm
Net Weight 5.8kg 6.2kg
